He then shows XRD for KCl and KBr powders and says that KCl, while fcc, simulates a sc lattice with lattice constant a/2 and KBr is fcc. However, in the XRD plots, KCl has FEWER peaks than KBr. I would have thought the opposite: that all indices would show peaks for the sc, while only the all even/all odd indices would show peaks for KBr.

• KCl has a face-centered cubic Bravais lattice. However, the K + and the Cl − ion have the same number of electrons and are quite close in size, so that the diffraction pattern becomes essentially the same as for a simple cubic structure with half the lattice parameter.
• Results of X-ray studies are tabulated in the JCPDS (Joint Committee on Powder Diffraction Standards) Powder Diffraction File. The File is available on microfiche, and there is an annually updated index to the JCPDS file. Use the index to look up the data on KCl.

Abstract

The effects of high cumulative radiation dose on the luminescence properties of KCl:Eu²⁺ are investigated. Pellet samples of KCl:Eu²⁺ were given doses of up to 200 kGy at the Louisiana State University Synchrotron facility. After synchrotron irradiation, samples were optically bleached and given a clinical dose of 2 Gy from a 6 MV medical linear accelerator. Optical properties were evaluated using photostimulated luminescence (PSL), photoluminescence (PL), and temperature-dependent PSL measurements. For a cumulated dose of up to 5–10 kGy, the PSL emission intensity increased by 15% compared to the PSL signal with no radiation history. For doses higher than 10 kGy, the PSL emission intensity retained at least 70% of the original intensity. Spatial correlation of the charge storage centers increased for doses up to 5 kGy and then decreased for higher cumulative doses. Emission band at 975 nm was attributed to transitions of Eu¹⁺. PL spectra showed an intense peak centered at 420 nm for all cumulative doses. The results of this work show that KCl:Eu²⁺ storage phosphors are excellent reusable materials for radiation therapy dosimetry.

1. Introduction

Two-dimensional radiation therapy dosimeters require sub-millimeter spatial-resolution due to high dose gradient associated with modern radiation therapy treatment modalities such as IMRT (intensity modulated radiation therapy). In particular, a dosimeter should be reusable so that response variation from pixel to pixel can be quantified and therefore corrected. Radiographic film has been the detector of choice for IMRT dose distribution verification. Films can be inserted in any orientation in a phantom mimicking patient's anatomy, and it has unparalleled high spatial-resolution that is essential for verification of steep dose gradients. However, film is not reusable, and quantitative use requires the acquisition of a sensitometric curve for each measurement with a questionable assumption that individual films from a single batch and individual pixels on the same sheet share a common response. Also, the implementation of digital imaging in diagnostic and radiation oncology departments is causing departments to systematically remove film processors. In 2005, Olch showed that the BaFBrI:Eu²⁺-based computed radiography panels had the potential to be used for two-dimensional megavoltage radiation therapy dosimetry []. However, BaFBrI has a high Z number (Z_eff = 49) which leads to a strong photon energy dependence and consequently unacceptable measurement accuracy. Also, BaFBrI or CsBr-based detector panels were designed for diagnostic radiology where radiation doses are on the order of μGy-mGy. For radiation therapy, a typical fractionated dose for radiation therapy is 2 Gy. Therefore, a reusable dosimeter with tissue-like response, high spatial-resolution, and excellent radiation hardness properties is desirable for quantitative radiation therapy dosimetry.

Recently, we have shown that KCl:Eu²⁺-based dosimeters provide similar energy response as radiographic film [, ]. The Z_eff is 18, which is much closer to tissue than BaFBrI or CsBr. Further, we have shown that the luminescence properties of KCl:Eu²⁺ remain optimal for cumulative doses of up to 3000 Gy which means that a KCl:Eu²⁺-based dosimeter can be used at least 1500 times in the clinic before any signal degradation occurs []. A radiation resilient dosimeter allows for less frequent dosimeter calibration and, as a result, reduces measurement uncertainty. For comparison, it has been reported that the PSL signal of CsBr:Eu²⁺ starts to degrade after a few tens of Gy [5, 6].

In this work, we present the first attempt to explain why KCl:Eu²⁺ exhibits superior radiation hardness properties, compared to other alkali halide phosphors. We will examine the electronic environment and microstructure of KCl:Eu²⁺ dosimeters with high cumulative dose using low temperature photostimulated luminescence (PSL) spectroscopy, x ray diffraction, and photoluminescence (PL) emission spectroscopy.

2. Experimental

Pellets of KCl:Eu²⁺ (1 mm thick, 6 mm diameter) with 0.05 mole % Eu, were made using a hydraulic press using a procedure described earlier []. The XRLM4 beam line at the Center for Advanced Microstructures and Devices (CAMD) synchrotron facility at Louisiana State University was used for high dose irradiation of samples. The energy of the particles in the storage ring was 1.3 GeV with a 100 mA beam current. The energy spectrum emitted from the XRLM4 beamline was a Gaussian distribution with the peak energy of approximately 20 keV. A 175 μm Be window was used to filter out low energy wavelengths. Pellets were placed in an acrylic holder with circular holes with the spacing between each hole at 0.2–0.4 cm. The sample holder was moved in a vertical direction to ensure homogeneous irradiation along the sample surface.

Well organized and easy to understand Web building tutorials with lots of examples of how to use HTML, CSS, JavaScript, SQL, PHP, Python, Bootstrap, Java and XML. Php for loop.

After synchrotron irradiation, samples were shipped back to St. Louis, MO and were bleached of all radiation dose information using an intense halogen lamp. After bleaching, clinical doses of 2 Gy were given using a medical linear accelerator (Trilogy, Varian Medical System, Palo Alto, CA, USA). Solid-water phantoms (Gammex RMI, Middleton, WI) consisted of several 30×30 cm² slabs and were arranged to provide 10 cm of backscatter and the desired depth for irradiation. Dosimeter pellets were placed in a 0.5 cm thick slab machined with a linear array of holes across the center. PSL point measurements were obtained using a setup described earlier []. Low temperature measurements were obtained by placing dosimeters in a temperature-controlled cryostat (Model CCS-450, JANIS, Wilmington, MA). PL and PSL emission spectra were obtained using a Nanolog Spectrofluoremeter (Horiba Jobin Yvon Kyoto, Japan). A 450 W Xe lamp was used for the excitation source and the excitation light passed through a 1200 lines/mm grating to the solid sample. Emission light was detected using a Synapse Open-electrode CCD detector (Horiba, Kyoto, Japan) sensitive between 300–1000 nm.

3. Results and Discussion

Figure 1 shows the PSL sensitivity with various cumulated dose histories. Figure 1 shows that the sensitivity increases by 15% with a cumulative dose of 5 kGy and then decreases with higher cumulated doses. These results correlate well with previous results []. Batentschuk et al. [6] also reported a slight increase in PSL intensity for CsBr:Eu²⁺. Cumulative doses higher than 5 kGy result in a 20–30% loss of signal, relative to no dose history. In order to further investigate the changes in PSL with cumulative dose, we will focus on two questions.

PSL sensitivity with cumulated dose in KCl:Eu²⁺. The PSL sensitivity was normalized to the signal from fresh KCl:Eu samples with no cumulative dose. Samples were irradiated using the synchrotron facility at LSU. After optical bleaching, samples were given 2 Gy using a 6 MV medical linear accelerator and the PSL signal was measured. Samples were excited with 560 nm and emission was detected at 420 nm.

First, why does the PSL increase with cumulative dose?

The Takahashi model assumes the existence of F⁺ centers in the lattice prior to irradiation [7]. On the other hand, according to Itoh [8], the photostimulable centers in alkali halides can also be created by ionizing radiation by the process in which a self-trapped exciton undergoes an isomeric transformation to an F-H pair. Itoh's model suggests that electron and hole storage centers created by ionizing radiation are spatially correlated, which has been confirmed by von Seggern et al. [9]. After photostimulation, F-center electrons require thermal energy to be released from the relaxed excited state (RES) of the F-center into the conduction band. When the temperature is too low, an electron in the RES will not be able to thermally leave the F-center and, therefore, will either decay back into the F-center ground state or tunnel to a nearby V_k-center to recombine. However, in order for an electron to tunnel to a nearby V_k center, the F center must be physically close (spatially correlated) to the V_k center. Thus, PSL yield at low temperatures corresponds to the concentration of spatially correlated traps [, 11].

Figure 2 shows the spatial correlation of V_k and F-centers in KCl:Eu²⁺ for various cumulative doses. Samples were irradiated at 50 K in a cryostat chamber. Samples were left overnight in the dark, under vacuum, in order to avoid recuperation effects []. The next morning, PSL measurements were taken by stimulating with 560 nm light and collecting emission light at 420 nm. The PSL emission is only from the Eu²⁺ transition to the ground state. About 20% of the centers in the fresh sample were correlated, compared to 40% correlated for the 5 kGy sample, and 15% for the 200 kGy sample. The increase in spatially correlated centers for the 5 kGy sample coincides with the PSL intensity results shown in Figure 1, suggesting additional photostimulable traps are created as a result of ionizing radiation in addition to preexisting traps.

Normalized PSL intensity at 420 nm as a function of temperature in KCl:Eu²⁺ after x ray irradiation at 50 K. Samples were stimulated with 560 nm.

Second, what radiation damage effects are created by high accumulated dose in KCl:Eu²⁺?

Figure 3 shows the PSL emission spectra as a function of cumulative dose in the IR region. Samples were stimulated with 560 nm or F center light. All spectra were normalized to the peak intensity of the characteristic 420 nm PSL emission for KCl:Eu²⁺ (shown in Figure 5). Figure 3 shows the presence of an intense peak at 975 nm for dosimeters with cumulative dose. Kao and others have observed similar bands near 875, 980 and 1130 nm and attributed these bands to the 4f⁷6s¹ → 4f⁶6s² transition of monovalent europium ions [13, 14]. The monovalent activator is created by a divalent ion capturing an electron induced by x ray irradiation. Kao showed that for KCl:Eu²⁺, the optical density of the 980 nm absorption increases at the expense of the Eu²⁺ absorption peak. Fong showed a similar result for KCl:Sm²⁺ [14]. Therefore, the data in Figure 3 suggests that cumulative radiation dose induces damage to the KCl lattice, which ultimately results in an increase in monovalent europium emission. Note that this band is approximately 5 orders of magnitude lower in intensity than 420 nm emission.

Using SmartShare Understand what SmartShare is. SmartShare is a program on your LG Smart TV. Lg screen share laptop. LG Smart Share is the tool that lets you connect your compatible smartphone, tablet, PC, camera, or USB device to your TV and showcases all of the device's audio, video,. Screen Sharing does not require additional software. Take a look at these videos to see how it works. Note: Screen sharing using a Mac or iOS device requires an Apple TV Streaming device. PC Screen Sharing Using Miracast (Windows 8.1 or higher) - webOS Video. How to Share your Windows 7 or 8 Screen on your LG webOS TV. Select Screen Share. Select Miracast. Select PC Windows 8.1 or later. Move the mouse cursor to the upper right or lower right corner of the screen to open the Charms menu. If this is the first time that you are connecting the TV to your PC, click Add a. After downloading the latest version of Smart Share (see link above), locate the downloaded file either from your web browser, or from your Downloads folder (shown here). The images below show the three most common browsers for PC users, Google Chrome, Firefox, and Internet Explorer respectively, and how to open the access the file from each.

PSL IR emission spectra of irradiated samples with cumulative dose history. Dosimeters were stimulated with F band light at 560 nm and the emission spectra were recorded. All spectra were normalized to 420 nm PSL intensity.

PL emission spectra for KCl:Eu²⁺ samples with different cumulative dose. The excitation wavelength was 350 nm.

We did not observe Eu³⁺ PL emission. This observation is consistent with Zimmerman et al. [5].

One reason for the resistance to radiation damage is the structural integrity of the KCl lattice, compared to other alkali halide materials. Savel'ev used electron paramagnetic resonance (EPR) to show that lattices with cesium cations were more susceptible to aggregations of activator ions, compared to lattices with potassium or rubidium cations[15]. The radiation-induced PSL quenching dose of KCl:Eu²⁺ is very high compared to CsBr:Eu²⁺ [5, 6].

X ray diffraction was used to obtain insight into how the microstructure of the KCl lattice is affected by cumulative dose. Figure 4 shows the x ray diffraction spectra for samples with various radiation history doses. Dosimeters remain highly crystalline for cumulative doses of 5 and 10 kGy. In fact, characteristic XRD peaks of the KCl lattice can still be observed for cumulative dose of 200 kGy. However, the spectral lines are not clear and distinct like the samples with lower cumulative doses. Significant radiation dose history does appear to introduce lattice distortions and defects into the crystal. The increase in defects within the KCl lattice coincides well with the decrease in spatially correlated storage centers, observed in Figure 2 and also coincides with the increase in the 975 nm band in Figure 3. The low intensity of the XRD peaks indicates that amorphous structures and inclusions may result from high cumulative dose. However, the PL spectra, shown in Figure 5, show an intense peak centered at 420 nm for all cumulative doses, even 200 kGy history. The slight red-shift in the peak intensity (about 4 nm) is due to the 10Dq splitting between the 5d orbitals []. Eu²⁺ emission is sensitive to the surrounding lattice structure. Therefore, the peak intensity of the Eu²⁺ emission would shift if new precipitate phases were induced by high radiation dose. However, the red shift is very small and indicates that the variation in the electronic structure with cumulative dose is very small. This observation indicates that although high cumulative dose may induce amorphous formations within the lattice, the energy storage and subsequent photostimulation remains efficient.

X-ray diffraction spectra of KCl:Eu²⁺ samples with various cumulative dose histories. The vertical lines indicate the peaks for KCl from the reference file PDF 00-001-0786.

4. Conclusions

The KCl:Eu²⁺ lattice is resistant to radiation damage which makes this material an excellent candidate for megavoltage radiation therapy dosimetry. The PSL signal retains at least 70% of the original signal for a cumulative dose of up to 200 kGy. Generation of additional spatially correlated storage centers may explain the increase in PSL with up to 5 kGy cumulative dose. High cumulative dose induces amorphous structure formation, monovalent europium emission, and a red-shift of Eu²⁺ PL emission.

Acknowledgments

The authors graciously acknowledge Dr. John Scott and Dr. Varshni Singh at Louisiana State University for their work irradiating our dosimeters at the synchrotron facility. This work was supported in part by NIH Grant No. R01CA148853.
